J.W Speaker Model 8700 EVO 2 Classic LED Headlights 557661

Specification:

• 8700 - EVO2 - Classic 12/24V DOT
• Height : 176.53 mm / 6.95 in
• Width : 176.53 mm / 6.95 in
• Depth : 99.82 mm / 3.93 in
• Shape : Round
• Outer Lens Material : Polycarbonate
• Outer Lens Color :  Clear
• Housing Material : Die-Cast Aluminum
• Housing Color:  Gray
• Bezel Color : Chrome
• Retrofits : 2D1 "PAR56" or 7" round headlight
• Minimum Operating Temperature : -40 °C / -40 °F
• Maximum Operating Temperature : 65 °C / 149 °F
• Connector or Wiring : H4
• Mating Connector: H4 AMP#172615-2
• Product Weight : 2.31 lbs / 1.05 kgs
• Shipping Weight : 4.00 lbs / 1.81 kgs

Electrical Specifications:

• Input Voltage : 12-24V Dc
• Operating Voltage :9-32V Dc
• Transient Spike Protection : 150v Peak @ 1 Hz-100 Pulses
• Black Wire : Ground
• White Wire : H igh Beam
• Yellow Wire : Low Beam

Current Draw:

• 3.5A @ 12v Dc (High Beam)
• 2.00A @ 12v Dc (Low Beam)
• 1.80A @ 24v Dc (High Beam)
• 1.10A @ 24v Dc (Low Beam)

Light Up Your Drive:

Your classic car is one of a kind – it deserves an exceptional headlight to stand out. The J.W. Speaker 8700 EVO 2 Classic LED headlight preserves the heritage vibe but makes a bold impact, day and night, without compromising the classic vintage look and feel of your car.

Drive anytime with confidence:

The J.W. Speaker 8700 Evo 2 Classic draws less than half the power of halogen lamps while providing a brighter, enhanced driving experience. Reduce the demand on your classic ride’s electrical system and your eyes at night.

Car aficionados know a sleek design is key:

J.W. Speaker designed the 8700 EVO 2 Classic headlight to be a simple install. Easy Retrofit: fits numerous classic cars that use a 7″/PAR56 style sealed beam headlamp and H4 connector.

Drive with style and safety:

The 8700 EVO 2 Classic is DOT approved and tested to be 100% street legal – unlike replacement LED bulbs. Make the Model 8700 EVO 2 Classic your primary choice for safety and vintage aesthetics.

Brand: J.W.Speaker
