JKS 2018-2022 Jeep Wrangler JL J-Max 3.5" Lift Kit JSPEC129KFC

Features & Benefits:

• Front FOX 2.5 Remote DSC Coilovers w/ Bolt-On Brackets for improved performance, strength and tunability.
•  Rear FOX 2.5 Piggyback DSC Coilovers w/ Bolt-On Brackets for improved performance, strength and tunability.
•  Front Adjustable Track Bar and Rear Track Bar Bracket to correct axle positioning under vehicle.
•  Front Sway Bar Quicker Disconnects and Rear Sway Bar Links for increased off road articulation.
•  Extended Length Braided Stainless Steel Rear Brake Lines.
•  Front/Rear J-Flex Upper Control Arms to add strength and adjustability.
•  Front/Rear J-Flex Lower Control Arms to add strength and adjustability.
•  Front/Rear Bump Stop Extensions to properly limit suspension up travel.

Components:

• JSPEC1313 (x1) 2018+ JL 3.5in J-Max Box Kit
• JKS1616 (x1) Jeep Wrangler JL Front Upper J-Flex Control Arms
• JKS1625 (x1) Jeep Wrangler JL Front Lower J-Flex Control Arms
• JKS1666 (x1) Jeep Wrangler JL Rear Upper J-Flex Control Arms
• JKS1661 (x1) Jeep Wrangler JL Rear Lower J-Flex Control Arms
• JKS2511 (x1) Jeep Wrangler JL Front Coil-over Mount Box Kit
• JKS2512 (x1) Jeep Wrangler JL Front Coil-over Bump Kit
• JKS2518 (x1) Jeep Wrangler JL Rear Coil-over Mount Box Kit
• FOX88406252 (x1) 18-ON Jeep Wrangler JL Front Coilover, 2.5 Series, R/R, 3.5" Lift, DSC
• FOX88406253 (x1) 18-ON Jeep Wrangler JL Rear Coilover, 2.5 Series, P/B, 3.5" Lift, DSC

Tire Specs:
Rubicon Models (all kits):

• 37x12.50 17x9, 18x9, 20x9 5" BS

Non-Rubicon Models (all kits):

• 35x12.50 17x9, 18x9, 20x9 5" BS
• Other tire/wheel sizes can be used, however may require additional modifications.

Important Notes:

• Factory wheels cannot be reinstalled without wheel spacers
• Aftermarket wheels with 3.5” backspacing are required for clearance
• Requires cutting/removal of factory frame mount brackets
• Front aftermarket driveshaft strongly recommended due to additional travel capability
• Removal of coilover preload required on 2Dr models to achieve a minimum 3.5” of lift
• Will NOT fit 4xe models
• Will NOT fit Rubicon 392 models
• Will NOT fit diesel models
• Fits Rubicon Models Only

J-Max pulls out all of the stops to offer a truly performance driven suspension package. At each corner are custom tuned FOX 2.5 factory race series coilovers with DSC adjustment. These coilovers offer race proven technology with a larger 2.5” diameter body, dual rate springs and (DSC) dual speed compression adjustment for maximum tunability. Each of the 8 control arms, upper and lowers, front and rear are upgraded to J-Flex adjustable control arm for improved strength, offroad performance and adjustability. In addition, these kits feature high strength bolt-on coilover mounting brackets, an adjustable front track bar, sway bar quicker disconnects and more offer take your Jeeps trail performance and strength to the next level. It should be noted that an aftermarket front driveshaft is strongly recommended due to additional travel capable.

Brand: JKS

• 2018-2022 Jeep Wrangler JL
